    Model No.:SC-ABC-M
    Parameter:

    Chip size :0.25mm²

    Wavelength of peak responsivisity:275nm

    Peak responsivisity (at 355 nm):0.097A/W

    Spectral response range (R=0.1×Rmax): 220-350nm

    UV-visible rejection ratio (Rmax/R400 nm): >10∧4

    Dark current (Vr = -1 V):<0.1 nA
